Shinechip
TSP-001D Black 3-Colour Mirror Touch Switch, 12V 12W
Switch, dim and change colour temperature from one touch point on dark-framed mirrors. TSP-001D in black blends behind darker mirror designs and gives users warm, neutral or cool light without a second control.
Wholesale orders welcome: standard models from 2 pcs, shipped in 7-15 days. We confirm price, lead time and custom options in the quote.
Why buyers choose TSP-001D
One touch point steps through three colour temperatures and dims, for mirrors with CCT strips.
The 73 x 46 x 13 mm black aluminium housing with white cable suits dark mirror backs, rated IP22.
110-240V AC input with 12V DC output at 1A / 12W; EU plug standard, US on request. MOQ 2 pcs.
TSP-001D in black is a capacitive touch switch for bathroom mirrors that switches, dims and steps through three colour temperatures from one touch point. The listing gives 110-240V AC input with 12V DC output at 1A / 12W, and it works through mirror glass 1-5 mm thick. The 73 x 46 x 13 mm aluminium housing is black with a white cable and rated IP22.
Key features
- Three-colour adjustment plus dimming
- 110-240V AC input, 12V DC output, 1A / 12W
- Works through 1-5 mm mirror glass
- Black aluminium housing with white cable, 73 x 46 x 13 mm
- IP22
- White and blue indicator light
- EU plug as standard, US plug on request
Specifications
| Model | TSP-001D |
| Function | 3-colour (CCT) + dimming |
| Type | Capacitive touch switch |
| Input voltage | 12V DC |
| Output voltage | 12V DC |
| Max load | 12W |
| Sensing range | 1-5 mm |
| Mirror thickness | 1-5 mm |
| IP rating | IP22 |
| Material | Aluminium |
| Dimensions | 73 x 46 x 13 mm |
| Indicator | White light / Blue light |
| Plug | EU plug as standard; US plug on request |
| Housing colour | Black case + White Cable |
Specifications from our Alibaba.com product listing. Confirm the version you need before ordering.
Where it is used
- Bathroom LED mirrors with dark frames
- Hotel bathroom mirrors
- Make-up mirrors with CCT strips
OEM options for this model
- Plug type (EU / US / UK / AU)
- Output power
- Logo and packaging
- Single-colour or 3-colour (CCT) function
Options depend on order quantity; we confirm what can change for this model in the quote.
Frequently asked questions
Do I need a separate driver?
The listing gives AC input with 12V DC output, so a separate driver is not needed for strips up to 12W. Confirm your mains voltage with us when you order.
Which plug comes with it?
EU plug as standard; note US plug on your order if you need it.
Which strip does it need?
A 12V CCT strip for the three-colour function, with the load within 12W.
What is the MOQ?
Standard orders start from 2 pcs. Ask us about samples for testing before your first order.
