ShinechipLED Strip & Mirror Accessories
Strip connectors, mains power cords and mirror hanging hooks are the last parts that finish an LED mirror or furniture light. Mix them into the same order as your switches and strips.
55205520 / 5515 / 6520 / 7508 Mirror Dovetail Hanging Hooks
WF-207WF-207 2-Pin Power Cord, 1.5 m, Bare Wire End, US or EU Plug
Led connector4-Pin 10 mm LED Strip Connector, 0-36V DC 5A
Why buyers source accessories from us
The 4-pin 10 mm connector, rated 0-36V DC and 5A, joins strip runs on site.
A 1.5 m power cord and mirror hanging hooks complete the mirror, mixed in the same order as switches and strips.
How to choose
- Match the connector to the strip: 4-pin, 10 mm, within 0-36V DC and 5A.
- Choose the power cord plug (US or EU); the bare end connects to the driver or mirror switch.
- Pick dovetail hooks by mirror size and weight.
Building a bathroom mirror? See the complete Bathroom Mirror kit →
Send these details for a quote
- Connector pin count, strip width and current per run
- Power cord plug type (US or EU) and length
- Mirror size and weight for the hook selection
- Quantity per item
Related articles
How much load can the 4-pin 10 mm connector carry?
The 4-pin 10 mm connector is listed for 0-36V DC and 5A. The current limit sets the wattage at your strip voltage: maximum watts = 5A x strip voltage. For any strip, calculate the run's current as watts per metre x length ÷ voltage and keep it below 5A at the connector.
A 4-pin connector suits strips with four conductors; match the pin order to the strip markings before pressing it closed. The connector is listed with a working temperature of 70°C, so keep it away from heat sources such as defogger pads and drivers.
Which mains cord and mirror hooks are available?
The WF-207 is a 2-pin power cord, 1.5 m long, with a bare wire end and a US or EU plug. The bare end is meant for connection to a driver or to a mirror switch with an internal supply. That connection is on the mains side: it must be made with the power off and by a qualified electrician, and the cord must be fixed so it cannot be pulled out of the terminal.
The 5520, 5515, 6520 and 7508 dovetail hanging hooks are cold-rolled steel. A dovetail pair has one part on the mirror and one on the wall, so the mirror slides down onto the wall part. Choose the hook by the mirror size and check the product page for the load the hook pair supports.
Compare by type
| Type | How it is triggered | Suited to | Typical models |
|---|---|---|---|
| 4-pin strip connector | Not switched; joins strip runs | Solder-free joins on 10 mm strips up to 5A | 4-Pin 10 mm LED Strip Connector |
| 2-pin power cord | Plug into the mains socket | Supplying mains to the driver or switch | WF-207 |
| Dovetail hanging hooks | Not electrical | Hanging the finished mirror | 5520, 5515, 6520, 7508 |
Compare accessories
| Model | Input | Max load | Range / size | MOQ |
|---|---|---|---|---|
| 5520 / 5515 / 6520 / 7508 Mirror Dovetail Hanging Hooks | - | - | - | 50 pcs |
| WF-207 2-Pin Power Cord, 1.5 m, Bare Wire End, US or EU Plug | - | - | - | 2 pcs |
| 4-Pin 10 mm LED Strip Connector, 0-36V DC 5A | 0-36V DC | - | - | 2 pcs |
Values from our Alibaba.com listings. Ask us to confirm the exact version before ordering.
Frequently asked questions
Can accessories be ordered in small quantities?
Yes. The connector and power cord are listed from 2 pcs and the mirror hooks from 50 pcs; see each product page.
Can accessories be packed with switches or strips?
Tell us which parts to pack together and we confirm what can be supplied.
Can the 4-pin connector be used on any low-voltage strip?
Only within its listing: 0-36V DC and 5A. Check the strip voltage is inside that range, then check the current, and keep the run below 5A at the connector.
Is the power cord supplied with a plug on both ends?
No. The WF-207 has a US or EU plug on one end and a bare wire end on the other, for connection to the driver or switch input by a qualified electrician.
Need an accessory for your project?
Send the switch type, voltage, load and quantity, or a photo of the switch you use today. We reply with model options, MOQ, price and lead time.
