MHD-1201-A03 / B02 IR Hand-Scan Mirror Switch, Clock, 12V 12W
A hand-scan mirror switch that also shows a clock and runs colour and anti-fog control. MHD-1201 lets hotel guests switch the light with a wave, keeping the glass clean, while the built-in supply keeps the mirror build simple.
Wholesale orders welcome: standard models from 2 pcs, shipped in 7-15 days. We confirm price, lead time and custom options in the quote.
Why buyers choose MHD-1201-A03
IR hand-scan switching means no fingerprints on the glass.
Clock display, colour adjustment and anti-fog functions add selling points to one mirror.
200-260V AC input, 12V DC at 1A / 12W, for 5 mm mirror glass, 143 x 80 x 12 mm. MOQ 2 pcs.
MHD-1201 is an IR hand-scan switch for bathroom mirrors: a wave of the hand switches the light, so nobody has to touch the glass. It also shows a clock and handles colour adjustment and anti-fog. The listing gives 200-260V AC input with 12V DC output at 1A / 12W, for mirrors 5 mm thick, in a 143 x 80 x 12 mm IP22 unit.
Key features
- IR hand-scan on/off, no touch needed
- Clock display
- Colour adjustment and anti-fog function
- 200-260V AC input, 12V DC output, 1A / 12W
- For 5 mm mirror glass
- 143 x 80 x 12 mm, IP22
- Blue indicator in on mode, white in off mode
Specifications
| Model | MHD-1201-A03/MHD-1201-B02 |
| Type | Mirror touch switch with clock display |
| Input voltage | 12V DC |
| Output voltage | 12V DC |
| Max load | 12W |
| Sensing range | 5 MM |
| Mirror thickness | 5 MM |
| IP rating | IP22 |
| Dimensions | 143 x 80 x 12 mm |
Specifications from our Alibaba.com product listing. Confirm the version you need before ordering.
Where it is used
- Hotel bathroom mirrors
- Bathroom LED mirrors
- Make-up mirrors
OEM options for this model
- Plug type (EU / US / UK / AU)
- Output power
- Logo and packaging
- Single-colour or 3-colour (CCT) function
Options depend on order quantity; we confirm what can change for this model in the quote.
Frequently asked questions
What is the difference between MHD-1201-A03 and MHD-1201-B02?
They are the two versions in the store SKU list. Tell us your strip type and we confirm which version fits.
Do I need a separate LED driver?
No. It takes 200-260V AC and outputs 12V DC for strips up to 12W.
Can you customise it?
Customisation is listed. Tell us the change and quantity and we confirm.
What is the MOQ?
Standard orders start from 2 pcs. Ask us about samples for testing before your first order.
