YK-SMK001 Infrared Door Sensor Switch, 12V 60W / 24V 100W
Give your cabinets light that follows the door: on when it opens, off when it closes. YK-SMK001 uses infrared sensing instead of a mechanical plunger, so there is no contact switch for the door to press.
Wholesale orders welcome: standard models from 2 pcs, shipped in 7-15 days. We confirm price, lead time and custom options in the quote.
Why buyers choose YK-SMK001
Infrared door sensing replaces the mechanical plunger, so installers do not need to line up a contact switch with the door.
Rated 5A: 60W on 12V DC or 100W on 24V DC, so one switch suits both strip voltages you stock.
Listed sensing range is 1-7 mm. Send your door gap and we tell you where to mount it; silver finish, from 2 pcs.
YK-SMK001 is an infrared door sensor switch for cabinets: the light comes on as the door opens and goes off when it closes, with no mechanical plunger. It is rated 5A, giving 60W on 12V or 100W on 24V DC, and has a silver finish. The listed sensing range is 1-7 mm; send us your door gap and we confirm the mounting position.
Key features
- Infrared door sensing
- Light follows the door: on when open, off when closed
- 12V DC 60W / 24V DC 100W
- 5A maximum current
- Silver finish
Specifications
| Model | YK-SMK001 |
| Input voltage | 12V / 24V DC |
| Max load | 60W at 12V / 100W at 24V |
| Sensing range | 1-7 mm |
Specifications from our Alibaba.com product listing. Confirm the version you need before ordering.
Where it is used
- Kitchen cabinets
- Wardrobes
- Bathroom cabinets
OEM options for this model
- Lead length and connector (DC, Dupont, SM)
- Housing colour
- Sensing distance within the model's range
- Logo and packaging
Options depend on order quantity; we confirm what can change for this model in the quote.
Frequently asked questions
What door gap does it need?
The listed sensing range is 1-7 mm. Tell us your gap and door material and we confirm.
Single or double door?
It is a single-door sensor. For double doors, ask us about our double-door infrared switches.
What load can it take?
60W on 12V or 100W on 24V, 5A.
What is the MOQ?
Standard orders start from 2 pcs. Ask us about samples for testing before your first order.
