Shinechip
Illustration based on our product photo
SP530E CCT LED Strip Controller with Remote, 5-24V 6A
Sell tunable-white strip kits with a remote that shifts light from warm to cold and sets brightness. SP530E works with CCT strips from 5V to 24V, so one controller covers your kit range.
Wholesale orders welcome: standard models from 2 pcs, shipped in 7-15 days. We confirm price, lead time and custom options in the quote.
Why buyers choose this model
2-channel PWM output drives warm white and cold white, adjusting colour temperature and brightness.
Wireless remote range is listed at 20 m, so it works across a room or from the far end of a ceiling run.
DC5-24V, 6A, common-anode wiring, 1 W standby, white housing about 0.1 kg. From 2 pcs.
SP530E is a 2-channel PWM controller for tunable-white LED strips that mix warm and cold white. It adjusts colour temperature and brightness from a wireless remote at up to 20 m. The controller runs on DC5-24V, outputs 6A on a common-anode connection, and draws 1 W on standby, so it pairs with CCT strips from 5V to 24V in cabinets and ceilings.
Key features
- 2-channel output for warm white and cold white
- Wireless remote, range listed at 20 m
- DC5-24V input, 6A output
- Common-anode wiring
- Static power consumption 1 W
- White plastic housing, about 0.1 kg
Specifications
| Material | Plastic |
Specifications from our Alibaba.com product listing. Confirm the version you need before ordering.
Where it is used
- Kitchen cabinet CCT strips
- Bedroom and living room cove lighting
- Mirror and vanity CCT strips
OEM options for this model
- Remote key layout
- Logo on remote and box
- Packaging
Options depend on order quantity; we confirm what can change for this model in the quote.
Frequently asked questions
Does it work with single-colour strips?
It is built for 2-channel CCT strips. For single-colour strips choose one of our 1-channel dimmers.
Which strips are compatible?
Common-anode CCT strips from 5V to 24V DC. Tell us your strip voltage and wattage and we confirm the load fits within 6A.
What is the remote range?
The listing gives up to 20 m. Walls and metal cabinets can shorten it, so mount the receiver where the signal is not blocked.
What is the MOQ?
Our Alibaba.com store lists an MOQ of 2 pcs for this model. Ask us about samples for testing before a volume order.
